External MiniSAS-HD Cable

Luxshare-TECH 12Gbps External MiniSAS-HD 4X cable assembly can provide good SI and mechanical performance and quality.


FEATURES & BENEFITS
  • Compliant with SFF-8644, SFF-8086,SFF-8614
  • 4x (4 channels) base configuration
  • Applying for the interconnection between server and storage, or AI architecture etc
  • I2C for EEPROM communication
  • Support External SAS3.0,rate up to 12G
  • 100 Ohms differential impedance
  • Pull to Release latch design
  • 30AWG and 24AWG cable available
  • Relative Humidity < 80%
  • 360 degree EMI crimping shielding
  • All parts meet RoHS or PCB and raw cable meet HF, other parts meet RoHS
了解更多

Product Numbers Product Description
LA0HE002-SD-R 1.0m/30AWG, External MiniSAS-HD 4x cable assembly
LA0HE003-SD-R 2.0m/30AWG, External MiniSAS-HD 4x cable assembly
LA0HE004-SD-R 3.0m/30AWG, External MiniSAS-HD 4x cable assembly
LA0HE005-SD-R 1.0m/28AWG, External MiniSAS-HD 4x cable assembly
LA0HE006-SD-R 2.0m/28AWG, External MiniSAS-HD 4x cable assembly
LA0HE007-SD-R 3.0m/28AWG, External MiniSAS-HD 4x cable assembly
LA0HE008-SD-R 4.0m/28AWG, External MiniSAS-HD 4x cable assembly
LA0HE009-SD-R 3.0m/26AWG, External MiniSAS-HD 4x cable assembly
LA0HE010-SD-R 4.0m/26AWG, External MiniSAS-HD 4x cable assembly
LA0HE011-SD-R 5.0m/24AWG, External MiniSAS-HD 4x cable assembly
LA0HE012-SD-R 6.0m/24AWG, External MiniSAS-HD 4x cable assembly
