E-OSFP(800G)/U-OSFP(400G)

Luxshare-TECH Extreme/Ultra OSFP board I/O connector combines 8channels operating at speeds up to 112Gbps/56Gbps per channel into one affordable high-density interface(OSFP) mating with copper cable assembly oroptical Transceiver. The total port bandwidth is up to 800Gbps/400Gbps.


FEATURES & BENEFITS
  • Using 60 position PT (Pluggable Transceiver) SMT connector with 8 channels
  • Ultra/Extreme OSFP I/O connector and cage mating with the standard 400Gbps/800Gbps optical transceiver and copper cable
  • Employ 8 lanes operated up to 56G PAM4 modulation or 112G PAM4 modulation
  • Providing solutions up to 400Gbps or 800Gbps aggregated bandwidth
  • Belly to belly application
了解更多

Product Numbers Product Description
PEPB60-6310-000-1H  Extreme OSFP Connector with solder fixture,30u"Au
PEPB60-6311-000-1H  Extreme OSFP Connector without solder fixture,30u"Au
PEP060-7521-000-1H Extreme OSFP 112G conn
PEPC11-E000-0AS-0R OSFP 1X1 RHS CAGE, DIP, open top & bottom, w/o HS, w/o LP
PEPC11-E200-000-0R OSFP 1X1 CAGE, w HS 14.2MM, EMI, w/o LP
PEPC11-E202-000-0R OSFP 1X1 CAGE, w HS 14.2MM, w/o LP
PEPC11-E300-010-0R OSFP 1x1 Cage, w/o HEAT SINK, w/o LP
PEPC11-E300-0AG-0R OSFP 1X1 CAGE, 24 EON, open top, w thermal pad Honeywell, w/o LP
PEPC11-E300-0AS-0R OSFP 1X1 RHS CAGE, DIP, open top, w HS, w/o LP
PEPC12-E300-010-0R OSFP 1X1 CAGE, w/o HS&LP
PEPL40-E004-000-0R  OSFP Light-pipe assembly 1x4
PEPC11-E300-100-0R Extreme/Ultra OSFP 1X1 CAGE
PEPC11-E300-100-0R Extreme/Ultra OSFP 1X1 CAGE, normal EON,with logo, nickel preplating
PEPC41-E300-100-0R Extreme/Ultra OSFP 1X4 CAGE, normal EON,with logo, nickel preplating
